Getting Started
TDS1000/2000-Series Digital Oscilloscope User Manual
7
Probe Check Wizard
You can use the Probe Check Wizard to quickly verify that your
probe is operating properly. The wizard also helps you adjust the
probe compensation (usually adjusted with a screw on the probe
body or probe connec tor) and set the Probe option attenuation factor
in the vertical menu (for example, the menu that appears when you
push the CH 1 MENU button).
You should do this each time you connect a probe to an input
channel.
To use the Probe Check Wizard, push the PROBE CHECK button. If
your probe is connected properly, compensated properly, and the
Probe entry in the oscilloscope VERTICAL menu is set to match
your probe, the oscilloscope will display a PASSED message at the
bottom of the screen. Otherwise, the oscilloscope will display
directions on the screen to guide you in correcting these problems.
NOTE. Probe check is useful for 1X, 10X, and 100X probes; it does
not work with t he EXT TRIG front-panel BNC.
To compensate a probe connected to the EXT TRIG front-panel
BNC, follow these steps:
1. Connect the probe to a ny channel BNC, such as to CH 1.
2. Push the PROBE CHECK button and follow the directions on the
screen.
3. After you verify that the probe functions properly and is
compensated, connect the probe to the EXT TRIG BNC.

Tektronix TDS2024 Specifications

General

Channels	4
Bandwidth	200 MHz
Sample Rate	2 GS/s
Record Length	2.5k points
Vertical Resolution	8 bits
Vertical Sensitivity	2 mV/div to 5 V/div
Timebase Range	5 ns/div to 50 s/div
Display Resolution	320 x 240 pixels
Math Functions	Add, Subtract, Multiply, Divide, FFT
Input Coupling	AC, DC, GND
Trigger Modes	Auto, Normal, Single
Trigger Types	Edge, Video, Pulse
Connectivity	USB
Input Impedance	1 MΩ
Maximum Input Voltage	300 V
Interface	USB
Power Supply	100 to 240 V
Dimensions	326 mm x 158 mm x 124 mm
