Appendix D: Probe Basics
TDS3000B Serie s User Manual
D-9
P6139A replaceable parts and accessories
Index
number
Description
Part
number
1 Compensation box assembly 206-0440-00
2 BNC connector 131-3219-00
3 Cable cover nipple 200-3018-00
4 Cable assembly 174-0978-00
5 Ground collar 343-1003-01
6 Ground lead, 6 in 196-3113-02
7 Ground lead, 2.3 in 195-4240-00
8 Marker set (four colors, two each) 016-0633-00
9 IC Klipchip grabber, package of 20 206-0364-00
01 Adjustment tool 003-1433-01
11 Ground lead with clip, 6 in 196-3305-00
12 Probe tip assembly 206-0441-00
13 Probe tip cover 204-1049-00
14 Retractable hook tip 013-0107-06
15 Ground lead, 3 in 196-3113-03
16 Probe to connector pin adapter 015-0325-00
17
50 Ω BNC-to-probe tip termination and
adapter
013-0227-00
18 Ground contact kit (two each of five lengths)
with cover shell
016-1077-00
19 Grounding probe tip 013-0085-00
