Appendix G: Ethernet Set up
TDS3000B Serie s User Manual
G-13
Other Network Printer Settings
To verify that your oscilloscope is set to print to a network printer, do
the following steps.
1. Select a network printer in the Ethernet printer list. You select a
printer by using the general purpose knob to highlight a printer
name in the list.
2. Push the MENU OFF button to exit from the System I/ O menus.
3. Push UTILITY > System to select Hard Copy.
4. Push the Format bottom button and select the side button that is
correct for your network printer.
5. Push the Port bottom button and select the Ethernet side button.
6. Set Inksaver to ON to print the oscilloscope screen as a black on
white background image.
7. Push the MENU OFF button to exit from the System Hard Copy
menus.
Testing Network Printers
To te st tha t your oscilloscope is set to print to a network printer,
push the Hard copy button. The printer should print the current
screen to the selected network printer. If the print er does not print the
screen, refer to page to page G--7 for troubleshooting suggestions.
