To Next Page

To Previous Page

Getting Started

TDS3000B Serie s User Manual

1-31

Front-Panel Connectors

≈ 5V 

CH 4CH 3

CH 2CH 1

1MΩ, 13pF ≤150 VRMS CATl

PROBE COMP

≈ 5V 

EXT TRIG

50Ω

≤5VRMS

50Ω

≤5VRMS

1MΩ, 13pF ≤150 VRMS CATl

CH 2CH 1

50Ω

≤5VRMS

1MΩ, 17pF ≤150 VRMS CATl

1. PROBE C OMP. Square wave signal source to compensate

probes.

2. CH 1, CH 2, (CH 3, CH 4). Channel inputs with TekProbe

interface.

3. EXT TRIG. External t rigger input with TekProbe int erface

(two-channel models only).
