Reference
Options Settings Co mments
BW Limit
20 MHz, Off
Limits the ban
dwidth to reduce display noise;
filters the signal to reduce noise and other
unwanted high frequency components
Volts/Div Coarse, Fine Selects the resolution of the Scale k nob
Coarse define
s a 1-2-5 sequence. Fine
changes the resolution to s mall steps
between the coarse settings
Probe
See the next table
Push to adjust Probe options
Invert
On, Off Inverts (flips) the waveform with respect to
the refere
nce level
The option for voltage and current probes is different: Attenuation or Scale.
Probe op tio ns Settings Comments
Vo ltage ►Attenuation 1X, 10X, 20X, 50X, 100X,
500X, 1000X
Set to match the attenuation
factor of the voltage probe
to ensure correct vertical
readouts
Current ► Scale 5 V/A, 1 V/A, 200 mV/A,
100 mV/A, 50 mV/A,
20 mV/A, 10 mV/A, 1 mV/A
Set to match the scale of
the current probe to ensure
correct vertical readouts
Back Returns to the previous
menu
Knob
s
Vert
ical Position knobs. Use the vertical Position knobs to move the channel
waveformsupordownonthescreen.
Vertical Scale knobs. Use the vertical Scale knobs to control how the oscilloscope
amplifies or attenuates the source signal of channel waveforms. When you turn a
vertical Scale knob, the oscilloscope increases or decreases the vertical size of
th
e waveform on the screen.
Vertical Measurement Overrange (Clipping). Waveforms that extend beyond the
screen (overr ange) and display a ? in the measurement readout indicates an
invalid value. Adjust the vertical scaling to ensure the readout is valid.
Key Po ints
Ground Coupling. Use Ground coupling to display a zero-volt waveform.
Internally, the channel input is connected to a zero-volt reference level.
Fine Resolution. The vertical scale readout displays the actual volts/division
setting while in the fine resolution setting. Changing the setting to coarse does not
change the vertical scale until the Scale control is adjusted.
TPS2000B Series Digital Oscilloscope User Manual 121
