Preface
Conventions
This manual uses the following conventions:
Front-panel buttons, knobs and connectors appear as displayed. For example:
Help.
Menu options appear with the first letter of each word in upper case. For
example: Peak Detect, Window Zone.
Multipurp
ose knob
Front-pan
el buttons and knob labels - As displayed
Option buttons - First letter of each word on screen is upper case
NOTE. Option buttons may also be called screen buttons, side-menu buttons,
bezel buttons, o r soft keys.
The ► delimiter separates a series o f button pushes. For example, Utility
► Options ► RS232 Setup means that you push the Utility front-panel
but
ton, then push the Options option button, and then push the RS232 Setup
option button. Multiple pushes of an option button may be required to select
the desired option.
TPS2000B Series Digital Oscilloscope User Manual xvii
