Getting Started
TPS2000B Series Digital Storage Oscilloscopes are small, lightweight, benchtop
instruments, which you can use to take ground-referenced measurements.
This chapter describes how t o do the following tasks:
Take floating measurements
Install your product
Charge battery pack
s
Perform a brief functional check
Perform a probe check and compensate probes
Match your probe attenuation factor
Use t he self calibration routine
NOTE. You c an select a language to display on the screen when you power on the
oscilloscope. At any time, you can also access the Utility ► Language option to
select a language.
General Features
The next table and list d
escribe the general features.
Model Channels Bandwidth Sample rate
TPS2012B
2 100 MHz
1.0 GS /s
TPS2014B
4 100 MHz
1.0 GS /s
TPS2024B
4 200 MHz
2.0 GS /s
Battery powered or line powered
Two recha rgeable battery packs (second battery pack optional)
Independently isolated channels with no shared common ground
TPS2PWR1 Power Analysis application (optional)
Support for compatible voltage probes and current probes
Context-sensitive help system
Color LCD display
Selectable 20 MHz bandwidth limit
2500 point record length for each channel
Autoset
TPS2000B Series Digital Oscilloscope User Manual 1
