Appendix A: TPS2000B Specifications
Table 3: Vertical Specifications (cont.)
Characteristics Description
±3% for Sample or Average acquisition mode, 5 V/div to 10 mV /divDC Gain Accuracy
±4% for Sample or Average acquisition mode, 5 mV/div and 2 mV/div
Measurement Type Accuracy
Average of ≥ 16 waveforms with
vertical position at zero
±(3% × reading + 0.1 div + 1 mV) when 10 mV/div or
greater is selected
DC Measurement Accuracy,
Average Acquisition Mode
Average of ≥ 16 waveforms with
vertical positionnot at zero
±[3% × (reading + v ertical position) + 1% of vertical
position + 0.2 div]
Add 2 mV for settings from 2 mV/div to 200 mV/div
Add 50 mV for settings from > 200 mV/div to 5 V/div
Volts Measurement
Repeatability, Average
Acquisition Mode
Delta volts between any two
averages of ≥ 16 waveforms
acquired under same setup and
ambient conditions
±(3% × reading + 0.05 d iv)
1
When th
everticalscaleissetto>5mV/div.Whenthevertical scale is set to 5 mV/div, the bandwidth specification is typical.
2
The oscilloscope reverts to Sample mode when the SEC/DIV (horizontal scale) is set from 2.5 μs/div to 5 ns/div on 100 MHz models, or from 2.5 μs/div to
2.5 ns/div on a TPS2024B model. Sample mode can capture 1 2 ns glitches.
Table 4: Horizontal Specifications
Characteristics Description
TPS2012B and TPS2014B TPS2024BSample Rate Range
5S/sto1GS/s 5S/sto2GS/s
Waveform Interpolation (sin x)/x
Record Length
2500 samples for each channel
TPS2012B and TPS2014B TPS2024BHorizontal Scale (Sec/Div)
Range
5ns/divto50s/div,ina1,2.5,
5 sequence
2.5 ns/div to 50 s/div, in a 1, 2.5, 5 sequence
Sample Rate and Delay Time
Accuracy
±50 ppm over any ≥1mstimeinterval
Conditions
Accuracy
Single-shot, Sample mode ±(1 sample interval + 100 ppm × reading + 0.6 ns)
> 16 averages
±(1 sample interval + 100 ppm × reading + 0.4 ns)
Delta Time M easurement
Accuracy (Full Bandwidth)
Sample interval = s/div ÷ 250
2.5 ns/div to 10 ns/div (-4 div × s/div) to 20 ms
25 ns/div to 100 μs/div (-4 div × s/div) to 50 ms
250 μs/div to 10 s/div (-4 div × s /div) to 50 s
Position Range
25 s/div to 50 s/div (-4 d iv × s/div) to 250 s
TPS2000B Series Digital Oscilloscope User Manual 125
