Appendix A: TPS2000B Specifications
Table 9: Oscilloscope General Specifications (cont.)
Characteristic Description
Probe Compen sato r Output
Output Voltage, typical 5 V into ≥ 1MΩ load
Frequency, typical 1 kHz
Power Source
Source Voltage of the
Oscilloscope AC Adapter
100 to 240 VAC
RMS
50/60 Hz
Power Consumption
Less than 40 W
Environmental
Enclosure Rating
IP 40
2
except when the CompactFlash card and optional Application key are installed, the rating
becomes IP 30
2
.
Operating 0 °C to +50 °C
(+32 °F to +122 °F)
Temperature
3
Nonoperating
-40°Cto+71°C
(-40 °F to +160 °F)
Cooling Method
Forced air, temperature controlled
Operating High: +50 °C (+122 °F), 60% RH
Low: +30 °C (+86 °F), 90% RH
Humidity
3
Nonoperating
High: +55 °C to +71 °C (+131 °F to +160 °F),
60% RH max.
Low: 0°C to +30 °C(+32 °F to +86 °F), ≤90%
RH max.
Altitude
3,000 m (9,842 ft)
Operating 0.31 g
RMS
from 5 Hz to 500 Hz, 10 minutes on
each axis
Random Vibration w ith one
battery pack
Nonoperating
2.46 g
RMS
from 5 Hz to 500 Hz, 10 minutes on
each axis
Mechanical Shock with one
battery pack
Operating 50 g, 11 ms, half sine
Mechanical
Height
160.0 mm (6.33 in.)
Width
336.3 mm (13.24 in.)
Size, without front protection
cover
Depth
129.5 mm (5.10 in.)
Instrument only
2.7kg(6.0lbs)
With 1 battery
3.2kg(7.0lbs)
Weight (approximate)
With 2 batteries
3.7kg(8.0lbs)
TPS2000B Series Digital Oscilloscope User Manual 129
