Application Examples

CH1

Freq

1.000kHz

CH1

Period

1.000ms

CH1

Pk-Pk

5.04V

CH1

Rise Time

2.611µs?

CH1

Pos Width

500.0µs

40 TPS2000B Series Digital Oscilloscope User Manual
