Tektronix TriMode P7700 Series Technical Reference

Specifications
Specification
s
These specifi
cations apply to the P7700 Series probes when installed on an
MSO/DPO70000DX oscilloscope with a bandwidth greater than or equal to
20 GHz. The probe performance may be degraded if a probe is operated using
an oscilloscope with bandwidth less than the probe bandwidth. The probe and
oscilloscope must have a warm-up period of at least 20 minutes and be in an
environment that does not exceed the allowed e nvironmental limits. (See Table 5.)
Specifications for the P7700 Series TriMode Probes fall into two categories:
warranted and typical characteristics.
Warranted characteristics
Warranted characteristics describe guaranteed performance within tolerance limits
or certa
in type-tested requirements.
Table 4: Electrical characteristics
Characteristic Description
Differential mode
A, B mo de
Common mode
Rise time, small signal
1
Bandwidth filtered probe and probe tip fixture rise time, all input modes, and step gain settings
P7708
10% – 90%
<55 ps <55 ps <57 ps
20% – 80%
<35 ps <35 ps <35 ps
P7713
10% – 90%
<40 ps <40 ps <42 ps
20% – 80%
<28 ps <28 ps <28 ps
P7716
10% – 90%
<32 ps <32 ps <34 ps
20% – 80%
<24 ps <24 ps <24 ps
P7720
10% – 90%
<27 ps <27 ps <29 ps
20% – 80%
<18 ps <18 ps <19 ps
DC gain accuracy (probe and
probe tip fixture, all input modes
and step gain settings)
±2%, nominal DC gain, all
gain settings
Output zero with probe and probe
tip fixture (voltage measured at
probe output)
±4 mV
P7700 Series TriMode Probes Technical Reference 37
