AFA4000/E VAV Airflow Controller / p.141
Menu item
Option
Instructions
Input / Output
Diagnostics
> TLP POS F R
S1 X-X 0.0 - -
Sash 1 position.
An active output is shown with an X
beneath it. In the example shown here, the
tilt switch (T) and personnel sensor (P) are
active and the light curtain (L) is inactive as
shown by the X-X on the second row.
Parameters are:
T
Tilt switch
L
Light curtain
P
Personnel sensor
POS
Sash position. When in use, the
value goes from 0 (sash closed)
to 100% (sash fully open) to
show the position of the sash.
F
When Mute is pressed, an X
appears in the bottom row to
indicate that the motor is
driving forward.
R
When Mute is pressed, an X
appears in the bottom row to
indicate that the motor is
driving in reverse.
