3.6 External connections
3.6.1 Inputs
The AFA4000/E has the following inputs:
3.6.1.1 Input 1, Input 2, Input 3
These are volt-free inputs configurable for:
• Normally closed relays
• Normally open relays or
• Analogue 0 - 5 Vdc input
The inputs can be configured as:
Digital input functions (closed or
open volt free contact):
Note: Default values are:
Input 1: Night setback
Input 2: None
Input 3: Sash high
Fire Alarm
Sash high
Mute
Emergency
Fan stop
External alarm
Personnel sensor
Night set-back
Mains fail
Alarm disable
Sash warning
None
High / Low
Analogue input functions:
Duct pressure
Sash position
Volume pressure
Temperature
Damper feedback
3.6.2 Outputs
The AFA4000/E has the following outputs:
3.6.2.1 Relay outputs 1, 2, 3
These are volt-free outputs configurable for:
• Normally closed relays or
• Normally open relays
Note: Changeover relays are available with the Econ power supply relay interface unit. The
relay interface has an AUX relay output that can be selected to duplicate the action of
R1, R2 or R3 via a DIP switch.
