3.5 Operator display panel menu navigation
To scroll through menu items, press the ↑ and ↓ arrows, then press Mute to select an option.
3.5.1 Main menu
To display the Main Menu, from the Run Screen, press and hold the Mute button for 5 seconds
until the Main Menu is displayed.
Menu item
Option
Instructions
Run
Run screen
See Operation section
Set up Monitor
Monitor setup menu
See Monitor set up menu
section
Set up Auto Sash
Note: This option is only
available if the Auto Sash is
connected.
Auto Sash Configuration menu
See Auto Sash Configuration
menu section
3.5.2 Monitor set up menu
Menu item
Option
Instructions
Configure *
Monitor config menu
See section 8.
Calibration *
Calibration
See section 7.
Brightness
Screen Brightness
Adjust Brightness level then
press the Mute button.
Passwords *
Monitor passwords menu
Select the password to set:
• Admin
• Calibration
• Configure
Enter and re-enter the new
password, then press the
Mute button.
Select Done to return to the
Main menu.
