AFA4000/E VAV Airflow Controller / p.119
8.1.1 Monitor config menu
Note: A pop-up dialog box will show if a relay is already allocated to another option.
Menu item
Option
Instructions
Cal Config Menu
Cal config menu
See section 8.1.1.1.
Hours Counter
Hours counter menu
See section 8.1.1.2.
Input (1, 2 or 3)
Input activation
Select the activation type:
• Closed contact
• Open contact
• None
• Analog
Input function
Select the function:
• Night Setback
• Alarm Disable
• None
• Temperature
• Fire Alarm
• Mute
• Fan Stop
• Mains Fail
• Sash Warning
• High/Low
• Sash High
• Emergency
• Ext. Alarm
• Fire Alarm
Relay Output
(1, 2 or 3)
Relay activation
Select the activation type:
• Closed contact
• Open contact
Pushbutton (1,2, or
3)
Pushbutton activation
Enable or disable the timer.
Pushbutton function
• Fan
• Ext Fan
• D/F Fan
• Sockets
• S/B O/R
• Purge
• Light
• UV Lights
• Pump
• Gas
• High/Low Speed
• Emergency
Auto Dim Screen
Auto dim screen
Set the time to auto dim the screen.
Low Air Timer
Low air repeat time
Enable or disable the timer.
