9. Enter the required ID and press Mute.
10. Select Baud rate, then press Mute.
11. Select the required rate and press Mute.
12. Select Parity, then press Mute.
13. Select the required parity and press Mute.
14. Select Done, then press Mute.
10.2.3 BACnet settings
To setup the AFA4000’s BACnet settings:
1. From the Requires set up screen, press Mute, or from the Run Screen press and hold the
Mute button for 5 seconds until the Main Menu is displayed.
2. Select Set Up Monitor > Configure.
3. Enter the password (the factory default password is 0-0-0-0) and press Mute to continue.
4. Select Protocol, then press Mute.
5. Select BACnet, then press Mute.
6. Select BACnet Settings and press Mute.
7. The following parameters will be shown in a sub-menu:
Parameter
Description
Range
Default
A
Device
Instance
Set the Slave ID for the
unit
0000000 to 4194303
0000000
B
Station ID
Set the network ID
0-127
1
C
Baud rate
Set the required Baud
Rate
• 1200
• 9600
• 38400
• 2400
• 14400
• 57600
• 4800
• 19200
38400
D
Parity
Set the required Parity
Non/ Even/ Odd
None
E
Max Masters
Set the max masters
(max devices on the
network)
0-127
1
8. Select Device Instance, then press Mute.
9. Enter the required instance and press Mute.
10. Select Station ID, then press Mute. Enter the required ID and press Mute.
11. Select Baud rate, then press Mute.
12. Select the required rate and press Mute.
13. Select Parity, then press Mute.
