AFA4000/E VAV Airflow Controller / p.201
Auto Sash Controller
Options and features
BMS Outputs
Programmable volt-free (sash
position) outputs:
Voltage:
• 0 – 10 V
• 1 – 10 V
• 0 – 5 V
• 1 – 5 V
Current:
• 0 – 20 mA
• 4 – 20 mA
• Always Open / Closed
• Open / Close on sash fault alarm
• Open / Close on user detected
• Open / Close on obstruction
detected
• Open / Close on sash open /
closed
• Remote audible alarm
Control
Functions
Sash operation
• Manual sash operation (where
user detected) Tiptronic 'touch
sensitive' open/close
• Auto-Close (unoccupied
condition)
• Auto-Open (pushbutton enable
feature)
• Keypad Pushbutton open/close
• Footswitch open/close (optional)
• BMS input open / close
Alarms
Audible/visible indication
• Obstruction detected
• Sash fault
Status Indication
Keypad LCD display
Sash status (user present / open /
closing / closed etc)
Connections
Flying leads with plug-in
connections
(All cable lengths can be specified)
Agency Listing
CE RoHS
Mains Power
Protection
On-board fuse (F1)
3.15 A, 250 V rated
