Fig. 49: Physical Interfaces->AUX->AUX
The Physical Interfaces->AUX->AUXmenu consists of the following fields:
Fields in the Basic Settings menu.
Field Description
AUX Port Status Select whether the AUX port should be enabled or disabled.
The port is enabled by choosing ,. The port is disabled
by default.
Line Speed Only for AUX Port Status = enabled
Here you select the speed at which the gateway addresses the
modem (in bps).
Possible values:
• .!3,: The Baud rate of the serial terminal connection is
retained. (9600 in ex works state)
All other values mean that the modem is addressed at the cor-
responding speed in bps.
• )#
• )#
• $ )#
• + )# (default value): Recommended for communica-
tion with a GSM modem.
• )#: Recommended for communication with an ana-
11 Physical Interfaces Teldat GmbH
120 bintec Rxxx2/RTxxx2
