13.1.2 Radio Profile
Select which frequency band your WLAN controller shall use.
If the ?G @ !, is set then the 2.4 GHz frequency band is used.
If the ?G @ !, is set then the 5 GHz frequency band is used.
If the corresponding device contains two wireless modules, you can Use two independent
radio profiles. This assigns ?G @ !, to module 1 and ?G @
!, to module 2.
The function is activated by selecting ,.
The function is disabled by default.
13.1.3 Wireless Network
All of the configured wireless networks (VSS) are displayed in the list. At least one wireless
network (VSS) is set up. This entry cannot be deleted.
Click on to edit an existing entry.
You can also delete entries using the icon.
With Add, you can create new entries. You can create up to eight wireless networks (VSS)
for a wireless module.
Note
If you wish to use the default wireless network that is set up, you must at least change
the Preshared Key parameters. Otherwise you will be prompted.
13.1.3.1 Change or add wireless networks
Click on to edit an existing entry.
With Add, you can create new entries.
The following parameters are available
Network Name (SSID)
Enter the name of the wireless network (SSID).
13 Wireless LAN Controller Teldat GmbH
156 bintec Rxxx2/RTxxx2
