all Managed Access Points is displayed.
For each managed AP you will see an entry with the following parameter set: Update firm-
ware, Location, Device, IP Address, LAN MAC Address, Firmware Version , Status.
Click the Select all button to select all of the entries for a firmware update. Click the
Deselect all button to disable all entries and to then select individual entries if required
(e.g. if there is a large number of entries and only individual APs are to be given software
updates).
Possible values for Status
Status Meaning
Image already exists. The software image already exists; no update is required.
Error An error has occurred.
Running The operation is currently in progress.
Done The update is complete.
The Wireless LAN Controller->Maintenance->Firmware Maintenance menu consists of
the following fields:
Fields in the Firmware Maintenance menu.
Field Description
Action
Select the action you wish to execute.
After each task, a window is displayed showing the other steps
that are required.
Possible values:
• 0) #&# #!1: You can also start an update
of the system software.
• * "! 3 1 # !: You
can save a configuration which contains the AP status inform-
ation.
Source Location
Select the source for the action.
Possible values:
• ?(( # (default value): The file is stored respectively
on a remote server specified in the URL.
• 23 *!1 ! (, *: The file is on
the official Teldat update server. (Only for Action= 0)
#&# #!1)
Teldat GmbH
13 Wireless LAN Controller
bintec Rxxx2/RTxxx2 187
