Teldat bintec RT1202 User Manual

Fig. 95: Networking->Drop In->Drop In Groups->New
The Networking->Drop In->Drop In Groups->Newmenu consists of the following fields:
Fields in the Basic Parameters menu.
Field Description
Group Description Enter a unique name for the Drop In group.
Mode Select which mode is to be used to send the MAC addresses of
network components.
Possible values:
• (#) (default value): ARP packets and IP packets
belonging to the drop-in network are routed transparently
(unchanged).
• <&: ARP packets and IP packets related to the drop-in
network are forwarded with the MAC address of the corres-
ponding interface.
Network Configuration Select how an IP address is assigned to the routers of the Drop
In group.
Possible values:
• *" (default value)
14 Networking Teldat GmbH
236 bintec Rxxx2/RTxxx2
