The VoIP->Media Gateway->Extensions-> +New menu consists of the following fields:
Fields in the Basic Parameters menu.
Field Description
Description Enter the name of the extension.
Extension / User Name ISDN terminals: Enter the subscriber number the extension.
SIP terminals: Enter the user name.
A maximum of 40 characters can be entered.
Interface Type Select the interface type to be used.
The selection depends on the interfaces available.
Possible values:
• *: A SIP terminal device is used for the call.
• *.': An ISDN terminal device is used for the call. Can only
be selected if ISDN interfaces configured with Euro ISDN
point-to-multipoint (NT mode) are available.
• -, 3: An analogue terminal device is used for the call.
Can only be selected if analogue interfaces are available.
Select ISDN interface Only for Interface Type = *.'
Select an ISDN interface. The ISDN interfaces you can select
depends on the device used.
Select analogue inter-
face
Only for Interface Type = -, 3
Select an analogue interface.
Possible values:
• fxs5-1
• fxs5-2
• fxs5-3 (default value)
• fxs5-4
Registration Only for Interface Type = *
Specify whether the registration mechanism is to be used by
20 VoIP Teldat GmbH
404 bintec Rxxx2/RTxxx2
