Menu Position
ing list entry directly in the list.
Fig. 25: Configuration of the update interval
Fig. 26: Filter list
Structure of the GUI configuration menu
The menus of the GUI contain the following basic structures:
GUI menu structure
Menu Position
Basic configuration
menu/list
When you select a menu from the navigation bar, the menu of
basic parameters is displayed first. In a sub-menu containing
several pages, the menu containing the basic parameters is dis-
played on the first page.
The menu contains either a list of all the configured entries or
the basic settings for the function concerned.
Sub-menu The New button is available in each menu in which a list of all
the configured entries is displayed. Click the button to display
the configuration menu for creating a new list entry.
Sub-menu Click this button to process the existing list entry. You go to the
configuration menu.
Menu Click this tab to display extended configuration options.
The following options are available for the configuration:
GUI Configuration elements
Menu Position
Input fields e.g. empty text field
Text field with hidden input
8 Access and configuration Teldat GmbH
64 bintec Rxxx2/RTxxx2
