A.3.6 Configuration connector
The configuration connector installed is a DB9 female.
PIN Signal DB 9 female
2 TxD (Output)
3 RxD (Input)
5 GND
A.4 Technical specifications
A.4.1 Hardware architecture
PROCESSORS Freescale QorIQ processor.
MEMORY 256 MB in DDR3.
STORAGE UNIT FLASH Memory (32 Mbytes).
A.4.2 LAN interface
PROTOCOLS Ethernet (802.3).
PORTS 4-port switch managed through MDI/MDX autodetection.
SPEED 10/100/100 Mbps (BaseT).
CONNECTOR M12 8P X-Code female connector.
