Teldat H2 RAIL User Manual

Bandwidth (802.11n) 20/40 MHz (bundling two adjoining 20 MHz channels into one 40 MHz channel).
Bandwidth (802.11ac) 20 MHz; 40 MHz (bundling two adjoining 20 MHz channels into one 40 MHz chan-
nel); 80 MHz (bundling four adjoining 20 MHz channels into one 80 MHz channel)
A.4.5 GPS interface
STANDARDS NMEA.
SATELLITE CHANNELS Maximum 30 channels (16 GPS, 14 GLONASS) simultaneous tracking.
CONNECTOR RF FME male.
ANTENNA 3.3 V Active.
Passive.
A.4.6 Configuration interface
INTERFACES This can be configured in two modes:
Asynchronous Port:
24 DCE. Hardware flow control is not permitted.
Local Console:
V.24 DCE only 8-N-1, without flow control.
PROTOCOLS Asynchronous Port:
AT, PPP, GPS-DATA.
SPEED Asynchronous Port:
300 at 115,200 bps.
Local console:
9,600 bps (configurable up to 115,200).
CONNECTOR DB9 female located on the front panel of the device.
A.4.7 Power
INPUT VOLTAGE Depending on the model:
+110 VDC.
+24 VDC.
INPUT CURRENT Depending on the model:
180 mA @110 VDC or
830 mA @24 VDC.
MAXIMUM POWER 30 W.
Teldat S.A.
Technical information
Teldat H2 RAIL 27
