Teldat H2 RAIL User Manual

5 GHz Operation
Automatic Rate Selection (ARS) Available.
Transmission rate Automatic.
Data rates for 802.11b,g (2.4
GHz)
11, 5.5, 2 and 1 Mbps (DSSS modulation);
54, 48, 36, 24, 18, 12, 9 and 6 Mbps (OFDM modulation)
Data rates for 802.11a,h (5
GHz)
54, 48, 36, 24, 18, 12, 9 and 6 Mbps (OFDM modulation).
Data rates for 802.11n, Long
Guard (800ns), 20 MHz
MSC0 6,5 Mbps; MSC1 13 Mbps; MCS2 19,5 Mbps; MCS3 26 Mbps; MCS4 39
Mbps; MSC5 52 Mbps; MCS6 58,5 Mbps; MCS7 65 Mbps; MCS8 13 Mbps; MCS9
26 Mbps; MCS10 39 Mbps; MCS11 52 Mbps; MCS12 78 Mbps; MCS13 104
Mbps; MCS14 117 Mbps; MCS15 130 Mbps.
Data rates for 802.11n, Short
Guard (400ns), 20 MHz
MSC0 7,2 Mbps; MSC1 14,4 Mbps; MCS2 21,7 Mbps; MCS3 28,9 Mbps; MCS4
43,3 Mbps; MSC5 57,8 Mbps; MCS6 121,5 Mbps; MCS7 135 Mbps; MCS8 27
Mbps; MCS9 54 Mbps; MCS10 81 Mbps; MCS11 108 Mbps; MCS12 162 Mbps;
MCS13 216 Mbps; MCS14 243 Mbps; MCS15 270 Mbps.
Data rates for 802.11n, Long
Guard (800ns), 40 MHz
MSC0 13,5 Mbps; MSC1 27 Mbps; MCS2 40,5 Mbps; MCS3 54 Mbps; MCS4 81
Mbps; MSC5 108 Mbps; MCS6 121,5 Mbps; MCS7 135 Mbps; MCS8 27 Mbps;
MCS9 54 Mbps; MCS10 81 Mbps; MCS11 108 Mbps; MCS12 162 Mbps; MCS13
216 Mbps; MCS14 243 Mbps; MCS15 270 Mbps.
Data rates for 802.11n, Short
Guard (400ns), 40 MHz
MSC0 15 Mbps; MSC1 30 Mbps; MCS2 45 Mbps; MCS3 60 Mbps; MCS4 90
Mbps; MSC5 120 Mbps; MCS6 135 Mbps; MCS7 150 Mbps; MCS8 30 Mbps;
MCS9 60 Mbps; MCS10 90 Mbps; MCS11 120 Mbps; MCS12 180 Mbps; MCS13
240 Mbps; MCS14 270 Mbps; MCS15 300 Mbps.
Data rates for 802.11ac, Long
Guard (800ns), 20 MHz with two
spatial streams
MSC0 13 Mbps; MSC1 26 Mbps; MCS2 39 Mbps; MCS3 52 Mbps; MCS4 78
Mbps; MSC5 104 Mbps; MCS6 117 Mbps; MCS7 130 Mbps; MCS8 156 Mbps
Data rates for 802.11ac, Short
Guard (400ns), 20 MHz with two
spatial streams
MSC0 14,4 Mbps; MSC1 28,9 Mbps; MCS2 43,3 Mbps; MCS3 57,8 Mbps; MCS4
86,7 Mbps; MSC5 115,6 Mbps; MCS6 130,3 Mbps; MCS7 144,4 Mbps; MCS8
173,3 Mbps
Data rates for 802.11ac, Long
Guard (800ns), 40 MHz with two
spatial streams
MSC0 27 Mbps; MSC1 54 Mbps; MCS2 81 Mbps; MCS3 108 Mbps; MCS4 162
Mbps; MSC5 216 Mbps; MCS6 243 Mbps; MCS7 270 Mbps; MCS8 324 Mbps;
MCS9 360 Mbps
Data rates for 802.11ac, Short
Guard (400ns), 40 MHz with two
spatial streams
MSC0 30 Mbps; MSC1 60 Mbps; MCS2 90 Mbps; MCS3120 Mbps; MCS4 180
Mbps; MSC5 240 Mbps; MCS6 270 Mbps; MCS7 300 Mbps; MCS8 360
Mbps;MCS9 400 Mbps
Data rates for 802.11ac, Long
Guard (800ns), 80 MHz with two
spatial streams
MSC0 58,5 Mbps; MSC1 117 Mbps; MCS2 175,5 Mbps; MCS3 234 Mbps; MCS4
351 Mbps; MSC5 468 Mbps; MCS6 526,5 Mbps; MCS7 585 Mbps; MCS8 702
Mbps; MCS9 780 Mbps
Data rates for 802.11ac, Short
Guard (400ns), 80 MHz with two
spatial streams
MSC0 65 Mbps; MSC1 130 Mbps; MCS2 195 Mbps; MCS3 260 Mbps; MCS4 390
Mbps; MSC5 520 Mbps; MCS6 585 Mbps; MCS7 650 Mbps; MCS8 780 Mbps;
MCS9 866,7 Mbps
Output power limitation (without
antenna gain)
Adjustable in the following steps: 5, 8,11,14,16 dBm and maximum. Maximal
power varies depending on data rate, frequency band and country setting.
Technical information Teldat S.A.
26 Teldat H2 RAIL
