USB USB Interface Status Off -> system stopped.
Red -> interface is unavailable because it is installing, it is dis-
abled (shutdown) or due to auto-test failure.
Amber -> idle.
• Rapid blinking. It has not registered in the network or the quality
is insufficient.
• Slow blinking. GSM connection (GPRS).
• Steady. WCDMA (UMTS / HSDPA) connection.
Blinking (green/red) -> activity/maintenance.
Wi-Fi 1 Wifi-1 Interface Status Off -> Interface not available or not installed (not supported).
Red -> Interface not found, no data connection.
Amber -> Connecting.
Green -> Communications established. Blinking: depends on the
activity.
Wi-Fi 2 Wifi 2 Interface Status Off -> Interface not available or not installed (not supported).
Red -> Interface not found, no data connection.
Amber -> Connecting.
Green -> Communications established. Blinking: depends on the
activity.
LAN Switch LAN Switch interface activity Green -> connected. Blinking: connection data activity.
Red -> disconnected.
Off -> interface off.
Eth WAN Base-T Green -> connected. Blinking: connection data activity.
Off -> not used.
SFP Green -> connected. Blinking: connection data activity.
Off -> not used.
Cell Status Off -> system stopped.
Red -> interface is unavailable because it is installing, it is dis-
abled (shutdown) or due to auto-test failure.
Amber -> idle.
• Rapid blinking. It has not registered in the network or the quality
is insufficient.
• Slow blinking. GSM connection (GPRS).
• Steady. WCDMA (UMTS / HSDPA) connection.
Green -> connected. Blinking: connection data activity.
RSSI.
Coverage indication
Green -> Good level.
Amber -> Fair level.
Red -> Critical level.
