• +10~12dBm at MCS7/15
5.725~5.825 GHz Band:
• +12~15dBm at MCS0/8 , 1/9 , 2/10 , 3/11 , 4/12 , 5/13, MCS6/14
• +10~12dBm at MCS7/15
Bandwidth (802.11n) 20 MHz
40 MHz (bundling two adjoining 20 MHz channels into one 40 MHz channel).
A.5.7 USB Interface
3G USB MODEMS Please visit the Teldat website http://www.teldat.com for a list of supported 3G
USB modems.
SPEED The interface complies with the USB 2.0 (480 Mbps) standard; the end speed de-
pends on the 3G USB modem used.
CONNECTOR USB Type A.
A.5.8 Configuration Interface
LOCAL TERMINAL RS-232 9600-8-N-1 without flow control.
CONNECTOR RJ45 female on the device front panel.
A.5.9 Power Supply
INPUT VOLTAGE +12V DC.
INPUT CURRENT 1200 mA.
CONNECTOR Jack 5.5/2.5 mm.
A.5.10 Dimensions and weight
TYPE Desktop / chassis for a 1 U high Rack mount enclosure.
LENGTH x WIDTH x HEIGHT 245 x 210 x 45 mm.
WEIGHT 1.4 kg.
A.5.11 Environmental Specifications
TEMPERATURE OPERATING NORMALLY: 0 ºC to 45 ºC.
STORED: -25 ºC to 70 ºC.
RELATIVE HUMIDITY On: 5 % to 90 %.
Teldat S.A.
Technical Information
Teldat Router iM8 37
