Teldat M1 User Manual

A.5.1 LAN Connector
RJ45 LAN RJ45 PIN FE Signals GE Signals
1
2
3
4
5
6
7
8
BI-DA+
BI-DA-
BI-DB+
--
--
BI-DB-
--
--
BI-DA+
BI-DA-
BI-DB+
BI-DC+
BI-DC-
BI-DB-
BI-DD+
BI-DD-
A.5.2 WAN Connector
RJ45 WAN RJ45 PIN FE Signals GE Signals
1
2
3
4
5
6
7
8
BI-DA+
BI-DA-
BI-DB+
--
--
BI-DB-
--
--
BI-DA+
BI-DA-
BI-DB+
BI-DC+
BI-DC-
BI-DB-
BI-DD+
BI-DD-
A.5.3 WWAN Connector (female)
PIN ANT
Internal
External
RF in/out
GND
Teldat S.A.
Technical Information
Teldat Router M1/M1L 29

Teldat M1 Specifications

General

Form Factor	Desktop
WAN Ports	1
LAN Ports	4
USB Ports	1
VPN Support	IPsec, OpenVPN, PPTP, L2TP
Firewall	Stateful Packet Inspection (SPI)
Power Supply	12V DC
Operating Temperature	0°C to 40°C
Weight	250g
