A.6.6 USB Interface
3G USB MODEMS Please see the Teldat website http://www.teldat.com to get a list of the supported
3G USB modems.
SPEED The interface complies with the USB 2.0 (480 Mbps) standard; the end speed de-
pends on the 3G USB modem used.
CONNECTOR USB Type A.
A.6.7 Configuration Interface
LOCAL TERMINAL V.24 9600-8-N-1 without flow control.
CONNECTOR RJ45 female on the device’s front panel.
A.6.8 Power Supply
INPUT VOLTAGE +12V DC
INPUT CURRENT 1200 mA
JACK 5.5 mm
INTERNAL PIN 2.5 mm
A.6.9 Dimensions and weight
TYPE Desktop / chassis for a 1 U high Rack mount enclosure.
LENGTH x WIDTH x HEIGHT 245 x 210 x 45 mm.
WEIGHT 1.4 kg.
A.6.10 Environmental Specifications
TEMPERATURE OPERATING NORMALLY: 0 ºC to 45 ºC
STORED: -25 ºC to 70 ºC
RELATIVE HUMIDITY On: 5 % to 90 %
Technical Information Teldat S.A.
32 Teldat Router M1/M1L
