Appendix B Radio Information
B.1 RF LTE Specifications
The LTE equipment model with the MC7304 module offers LTE, DC-HSPA+, HSPA+, HSDPA, HSUPA, WCDMA,
GSM, GPRS, EDGE network connectivity over several radio frequency bands, in accordance with 3GPP Standards.
This product is supplied with antennas YWX-6221SAX9-508. To comply with the regulations, do not choose other
antennas.
Technology: LTE
Bands Frequencies Radiated Transmit Power
Band 3 Tx: 1710–1785 MHz
Rx: 1805–1880 MHz
+21 dBm ± 1 dBm
Band 7 Tx: 2500–2570 MHz
Rx: 2620–2690 MHz
+19 dBm ± 1 dBm
Band 20 Tx: 832–862 MHz
Rx: 791–821 MHz
+21 dBm ± 1 dBm
Technology: UMTS(WCDMA)/ HSDPA/ HSUPA/ HSPA+/ DC-HSPA+
Bands Frequencies Radiated Transmit Power
Band 1 Tx: 1920-1980 MHz
Rx: 2110-2170 MHz
+21 dBm ± 1 dBm
Band 8 Tx: 880–915 MHz
Rx: 925–960 MHz
+21 dBm ± 1 dBm
Technology: GSM / GPRS / EDGE
Bands Frequencies Radiated Transmit Power
EGSM 900 (900 MHz) Tx: 880–915 MHz
Rx: 925–960 MHz
+30 dBm ± 1 dBm
DCS 1800 (1800 MHz) Tx: 1710–1785 MHz
Rx: 1805–1880 MHz
+27 dBm ± 1 dBm
B.2 RF GSM/WCDMA Specifications
The GSM/WCDMA equipment model with the MC8705 module provides WCDMA, GSM, GPRS, EDGE network con-
nectivity over several radio frequency bands under 3GPP Standards.
This product is supplied with antennas YWX-6221SAX9-508. To comply with the regulations, do not choose other
antennas.
Technology: UMTS(WCDMA)
Teldat S.A.
Radio Information
Teldat Router M1/M1L 33
