Teldat M10-Smart - LAN Connectors; WAN Base-T Connectors; WAN SFP Connectors; WWAN Connector

A.4.1 LAN connectors
RJ45 LAN RJ45 PIN FE Signals GE Signals
1
2
3
4
5
6
7
8
BI-DA+
BI-DA-
BI-DB+
--
--
BI-DB-
--
--
BI-DA+
BI-DA-
BI-DB+
BI-DC+
BI-DC-
BI-DB-
BI-DD+
BI-DD-
A.4.2 WAN Base-T connectors
RJ45 WAN RJ45 PIN FE Signals GE Signals
1
2
3
4
5
6
7
8
BI-DA+
BI-DA-
BI-DB+
--
--
BI-DB-
--
--
BI-DA+
BI-DA-
BI-DB+
BI-DC+
BI-DC-
BI-DB-
BI-DD+
BI-DD-
A.4.3 WAN SFP connectors
SFP
Standard SFP connector
A.4.4 WWAN connector
Devices equipped with this interface have two SMA female connectors installed.
SMA Female PIN ANT
Teldat S.A.
Technical Information
M10-Smart 25
