Teldat M10-Smart - USB 3.0 Interface

Bandwidth 802.11n: 20/40 MHz
802.11ac: 20/40/80 MHz
802.11ax: 20/40/80 MHz
Antenna
Integrated directional dual-band MIMO array
A.5.7 USB 3.0 interface
TERMINAL Two USB 3.0 (Super Speed) host ports.
CONNECTOR Type-A.
A.5.8 Configuration interface
LOCAL TERMINAL RS-232 9600-8-N-1 without flow control.
CONNECTOR RJ45 female on the rear panel.
A.5.9 Power supply
INPUT VOLTAGE +12V DC.
INPUT CURRENT 3 A.
CONNECTOR Jack 5.5/2.5 mm.
A.5.10 Dimensions and weight
TYPE Desktop / chassis for a 1 U high Rack mount enclosure.
DIMENSION 232.8mm X 183.2mm X 45.2mm (excluding LTE antenna)
WEIGHT 0.6 Kg
A.5.11 Environmental specifications
TEMPERATURE OPERATING NORMALLY: 0 ºC to 40 ºC.
STORED: -25 ºC to 70 ºC.
RELATIVE HUMIDITY 10 % to 95 %.
Technical Information Teldat S.A.
30 M10-Smart
