Teldat V User Manual

TELDAT V – Installation Manual
I - 30
Doc.DM567-I
Rev.4.0
USB Interface
3G USB MODEMS
Please see the Teldat website www.teldat.com to
get a list of the supported 3G USB modems.
SPEED
The interface complies with the USB 2.0 (480
Mbps) standard; the end speed depends on the
3G USB modem used.
CONNECTOR
USB Type A
Configuration Interface
LOCAL TERMINAL
V.24 9.600-8-N-1-without flow control.
CONNECTOR
RJ45 female on the device front panel.
Power Supply
INPUT VOLTAGE
+12V DC.
INPUT CURRENT
1200 mA
JACK
5,5 mm
INTERNAL PIN
2,5 mm
External Power Supply
INPUT VOLTAGE
100-240V AC
INPUT CURRENT
1.0 A
INPUT FREQUENCY
50-60 Hz
Dimensions and weight
TYPE
Desktop.
LENGTH x WIDTH x
HEIGHT
242 x 179 x 48 mm.
WEIGHT
0.8 Kg.
Environmental Specifications
TEMPERATURE
OPERATING NORMALLY: 0ºC to 45ºC
STORED: -30ºC to 85ºC
RELATIVE HUMIDITY
On: 5% to 90%

Teldat V Specifications

General

Brand	Teldat
Model	V
Category	Network Router
Language	English
