MCC201/MCC201H User manual
Check the system start-up
Once the power is supplied to the camera, it will start booting. The system will boot up to an operating mode
after approximately 40 - 60 seconds. The green LED on the Ethernet port will flash indicating the system is
ready.
Encoder LED Display
These LEDs show that the camera is connected but a decoder is not connected.
Once the encoder is connected to a decoder, color of “LINK” LED will turn into green color and “ DATA” LED
will blink as video or audio transmissions occur.
Decoder LED Display
These LEDs show that the Decoder has started without connecting to an encoder. Once an encoder is
connected, the color of “LINK” LED will be turned to green and the “DATA” LED will blink as video or audio
data transmissions occur.
STATUS
LINK DATA
Red
Blinking
OFF
Red
Blinking
OFF
