MCC201/MCC201H User manual
Description of LEDs
System status can be monitored with LED display
LED State Description
PWR
Off Power off
Red Power on
STATUS
Green blinking Normally operating
Red System failure: Needs diagnostics
Constant change of colors between
Red and Green
NTSC/PAL setting does not match with input video
signal
Red blinking Failed to obtain IP address in DHCP mode
Constant change of colors
between Green blinking 2 times
and Red blinking once
Failed to register on DDNS server
Green blinking, Red blinks
once every 5 seconds
Video loss in Encoder system
Constant change of colors:
Green, Orange, Red color in turn
Formatting USB storage device
LINK
Off No connection to remote system
Green Connected to a remote system
Red blinking Decoder only: trying to connect to an Encoder
Orange
Illegal connection
(unsupported combination of system modes)
DATA
Green Data transmission in progress
Red Data loss
Off No data transmission
