38 • 4. Remote Configuration
MCC201/MCC201H User manual
This product has two sensor ports and two alarm ports.
When a decoder instead of a PC client is connected to encoder, one system becomes a Local system and
the other as a Remote system (in general a system which is being used by the user is called as Local
system). Then, actions for events can be configured for events from the remote system as well as for local
system. For example, it is possible to turn on an alarm device in local (center) decoder system when
a sensor device in remote end (site) encoder is triggered. Local section configures the actions for events
from local (self) system, and configuration activates local devices and Remote sections configure
the actions for events from remote (peer) system.
The following table lists the possible actions for events.
Action Description
Beep Triggers beep port.
Alarm out Triggers alarm (relay) port.
E-mail Sends E-mail to the specified address. AVI file can be attached.
FTP Upload AVI file to a specified FTP server.
Preset Move to the Preset position.
Local & Remote Event Configuration
Sensor1 / Sensor2
Configure the actions when the sensor is activated. Multiple actions can be set for a single event.
On Video Loss
Configure the actions when video input signal is lost. Multiple actions can be set for a single event.
On Motion
Configure the actions when motion is detected. Multiple actions can be set for a single event.
On Disconnect
Configure the actions when the link (connection) with peer system is disconnected. Multiple actions can
be set for a single event. This event happens when the last client which has been receiving video from
the camera loses the connection.
Alarm and Beep activation duration
Set the duration of alarm or beep activation in case of an event. If it is set to continuous, it will be in
active state until the operator resets it manually.
