TP-8/16/24/32/64S User Manual Version No.: V1.2
- 13 -
LED Color Status Explanation
PWR Green
Often lighted
The device has been charged
Non-lighted The device runs out of power
SYS
Green
Green
Flashed The device is in service
Non-lighted The device runs out of power or operates abnormally
POTS
Green
Green
Lighted Any POTS port has off-hook
Non-lighted POTS port has no off-hook
LINK
Green
Green
Lighted FE port is in LINK status
Non-lighted FE port is not in LINK status
ACT Green
Flashed FE port has data receiving and sending
Non-light FE port has no data receiving and sending
TXD Green
Flashed CONSOLE interface sends data
Non-light There has no data sending
RXD Green
Flashed CONSOLE interface receives data
Non-lighted There has no data receiving
To Next Page
