53
07
GNSS PDOP
Probability * 10; 0-500
08
GNSS HDOP
Probability * 10; 0-500
09
External Voltage
Voltage: mV, 0 – 30 V
10
GNSS Power
States:
0 – off state (when GPS module is off)
1 – Reserved
2 – GPS ready (antenna is working, but with no GPS
fix)
3 – GPS working (antenna is working and has GPS fix)
4 – GPS sleep (when device is in GPS sleep mode)
5 – Overcurrent (The only condition to get value 5,
then antenna is damaged and short circuit)
11
Movement Sensor
0 – not moving, 1 – moving.
12
Odometer Value
Distance between two records: m
13
GSM Operator
Currently used GSM Operator code
14
Speed (Km/h)
Value in km/h, 0 – xxx km/h
15
iButton ID
iButton ID number
16
Mode
0 – home on stop, 1 – home on move, 2 – roaming
on stop, 3 – roaming on move, 4 – unknown on stop,
5 – unknown on move
17
GSM Signal
GSM signal level value in scale 1 – 5
18
Deep Sleep
0 – not deep sleep mode, 1 – deep sleep mode
19
Cell ID
GSM base station ID
20
Area Code
Location Area code (LAC), it depends on GSM
operator. It provides unique number which assigned
to a set of base GSM stations. Max value: 65536
21
Dallas Temperature 1
10 * Degrees (°C), -55 - +115, if 3000 – Dallas error
22
Dallas Temperature 2
10 * Degrees (°C), -55 - +115, if 3000 – Dallas error
23
Dallas Temperature 3
10 * Degrees (°C), -55 - +115, if 3000 – Dallas error
24
Battery Voltage
Voltage: mV
25
Battery Charging Current
Current: mA
26
Ignition
Ignition status indication. Logic: 0 / 1
27
Network Type
0 – 3G network, 1 – 2G network
28
Continuous Odometer
Distance which device has been traveled with
ignition ON: m
29
Dallas temperature ID1
1
st
connected dallas temperature sensor ID
30
Dallas temperature ID2
2
nd
connected dallas temperature sensor ID
31
Dallas temperature ID3
3
rd
connected dallas temperature sensor ID
