TEM A07EXXXX – 1 Unit Transmitters Page 24
8.5 Rear Panel Description
Here the back side of transmitters is described. The rear panel support the Ventilation Fan, the Different Audio
input/output connectors, the different logic and TC-TS connectors, the RDS Programming input port, the GSM
Antenna Connector (Optional), the RS485 connector, and the AC Mains Switch.
Audio & Logic input-output connectors
