DIGITAL PID CONTROLLER
41
When PID control is set to Relay output code 3, the output cycle (Ct) is set to
20 seconds and the voltage pulse (SSR) output code is set to 1, the output
cycle (Ct) is automatically set to 2 seconds. When changing the setting, set it
separately.
9) Output group setting
The T50 series is categorized into S (standard) and D (heating/cooling) types,and
has both multiple inputs and outputs. The user may select among relay,SSR, or
SCR (4~20mA, DC) for output.
Enter to output setting group
Select of output1
Output action selection
Select of output2(cooling only)
Cycle time
Cycle time of cooling output
Cooling gain setting
Hysteresis
(ON/OFF control)
Hysteresis action selection
when ON/OFF control
Output1 volume when
input disconnected (OUT1)
Output2 volume when
input disconnected (OUT2)
High limit of output
Low limit of output
-
0(ON/OFF)/ 1(SSR)/
2(SCR)/ 3(Relay)
(Refer to p9, 2.2 )
REV ( Reverse action)
DIR (Direct action)
Dual (Heating & Cooling)
1 (SSR) /2 (SCR) /3 (Relay)
(P9, 2. 2) refer to the
Output configuration)
1 ~ 1000 sec.
1 ~ 1000 sec.
0.1 ~10.0
EUS
(0.0 ~ 100.0%)
Half / Normal
-0.5 ~ 105.0%
-0.0 ~ 105.0%
OL-L ~ 105.0%
-0.5% ~ OL-H
-
Always
Always
Heating &
Cooling Model
SSR / RELAY
control
Heating &
Cooling Model
Heating &
Cooling Model
ON/ OFF
control
ON/ OFF
control
Always
Heating &
Cooling Model
PID control
PID control
-
1(SSR)
REV
1(SSR)
2 sec.
2 sec.
1.0
2 ℃
NORM
0.0%
0.0%
100.0%
0.0%
display description setting range condition initial value
