DIGITAL PID CONTROLLER
3. Dimensions and Panel cutouts
11
1) T52 (48x96 mm) Dimensions
2) T53 (96x48 mm) Dimensions
3) T54 (48x48 mm) Dimensions
10.0 77.0
96.0
91.0
48.0
96.0
96.0
48.0
48.0
43.6
10.0
77.0
8.8
48.0
44.9
48.0
77.0
48.0
T52 / T53 (96x48)
Panel cutouts
(Unit: mm)
45
±0.5
92
±0.5
Min. 30
Min. 20
T54 (48x48) Panel cutouts
(Unit: mm)
Min.17
Min.17
45
+0.5
-0
45
+0.5
-0
