6) Alarm (Alarm1,2,3) group setting
The T50 series has three separate alarm outputs, and in the setting group,
alarms may be chosen among 21 types, and the dead band(Hysteresis) for the
alarm output may be set. Please find alarm code with the desired function in
the 'Alarm output type and Selection code' on the next page and use it to set
the alarm output in the settings mode.
Enter to alarm setting group
Alarm 1 output selection
Alarm 2 output selection
Alarm 3 output selection
Hysteresis of alarm 1 output
Hysteresis of alarm 2 output
Hysteresis of alarm 3 output
Delay time of alam1
Delay time of alam2
Delay time of alam3
Alarm 1 output value setting
Alarm 2 output value setting
Alarm 3 output value setting
Setting of the first alarm
output port
Setting of the second alarm
output port
Setting of the third alarm
output port
-
OFF / 1~21
OFF / 1~20
EUS (0.0~100.0%)
OFF / 1~240 sec.
PV alarm,
Deviation alarm
EU (-100.0 ~ 100.0 %)
AL1/ AL2/ AL3
Always
Always
Always
Always
When using
Alarm 1
When using
Alarm 2
When using
Alarm 3
When using
Alarm 1
When using
Alarm 2
When using
Alarm 3
When using
Alarm 1
When using
Alarm 2
When using
Alarm 3
When using
Alarm 1
When using
Alarm 2
When using
Alarm 3
-
3
OFF
OFF
1 ℃
1 ℃
1 ℃
OFF
OFF
OFF
EU(100.0%)
0 ℃
0 ℃
AL 1
AL2
AL3
display description setting range condition initial value
The HBA will be generated through alarm output #1 (when A1TY = 21). This
means that HBA may be set only through alarm output #1.
