Tenda A18 User Manual

3
1.3.2 Ports & Buttons

WPS button
Press the WPS button down for 1 second to perform WPS negotiation, the WPS LED
indicator blinks, and enable the WPS function of another device within 2 minutes to
establish a WPS connection.

RESET button
With the PWR LED indicator solid on, hold the RESET button down using a paper clip, and
release it when all the LED indicators blink once then turn off. Wait until the PWR LED
indicator lights solid on again, the repeater is reset successfully.

LAN port
− In Repeater mode, this port allows a wired device, such as a desktop computer, to be
connected to the repeater to access the internet.
− In AP mode, it is used to connect to your upstream device such as a wired router,
enabling the repeater access the internet.
WPS button
RESET
button
LAN port

Tenda A18 Specifications

General

Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	867 Mbit/s
Supported data transfer rates	11, 54, 300, 867 Mbps
Security algorithms	SSID, WPA-PSK, WPA-TKIP, WPA2-PSK
Product type	Network repeater
Product color	White
LED indicators	Power, Signal strength, WPS
DC input voltage	9 V
Power source type	DC
Power consumption (max)	5.2 W
Power consumption (typical)	2.8 W
Frequency band	2.412 - 2.484, 5.15 - 5.25 GHz
Channels quantity	2 channels
Transmission gain	12 - 16 dB
Receiver sensitivity	-97 dBm, -76 dBm, -74 dBm, -72 dBm, -95 dBm, -63 dBm
Antennas quantity	2
Antenna gain level (max)	2 dBi
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Flash memory	8 MB
RAM capacity	64 MB
Harmonized System (HS) code	85176990

Weight and Dimensions

Dimensions (WxDxH)	58 x 48 x 80 mm
