Tenda AC15 User Manual

112
LAN IP
Here you can customize a LAN IP for your Router.
When you use the wireless repeating feature, you might need to change the LAN IP address in case
there is an IP conflict between the LAN IP of the Router and base station.
DHCP Server
DHCP server can automatically assign the broadband service information (IP Address, Subnet Mask,
Gateway and DNS Server Address) to the computer or smartphone, or other devices in your network
wirelessly or via Ethernet cables. Do not disable this function until you want to configure the IP
address manually for each device in your network by yourself.
Tips
The DHCP Server option will be unchecked automatically when you use the Universal Repeater
(Client + AP) feature.
IP Address Range
When the DHCP server is enabled, the Router will assign IP addresses to the attached devices. IP
address range is the range of there IP addresses.
Lease Time
Select the lease time of the IP assigned automatically, say 1 day. When the lease time is used up, the
IP will renew automatically. So you don’t need to reset it manually.

Tenda AC15 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, System, USB, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Bandwidth (first)	5 GHz
Bandwidth (second)	2.4 GHz
Mobile network connection	No
WLAN data transfer rates supported	600, 1300 Mbit/s
Antenna gain level (max)	3 dBi
Output current	2.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Routing protocols	IP
Security algorithms	WPA, WPA2, WPA2-PSK, WPS
Certification	CE, FCC, RoHS, BSMI, NCC, EAC, C-tick, IC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	76.6 mm
Width	226 mm
Height	179.5 mm
Weight	1210 g
