Tenda AC15 User Manual

118
Method Two: Press and hold the RST button on the top panel for about 8 seconds and then release
it to reset the Router to factory default settings.
Note
1. During the restoration, do not disconnect the power of the Router and other relevant devices.
2. After you restore the Router to factory default, you need to reconfigure the Router for accessing
the Internet.
3. Strongly recommend you not to restore the Router, unless the following sequence appears:
 You have to access the Router but you cannot remember the login name and password.
 Your Router does not work well, and you want to reconfigure it by following the Setup Wizard.
 You cannot access the Internet, and Tenda technical support recommends you to restore to factory
default.
System Log
If you want to have a good knowledge of system operation, or when you have difficulties in surfing
the Internet, you need to send your system logs to Tenda technical supporters.
Log in to the Router’s User Interface, and click Administration > System Log.

Tenda AC15 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, System, USB, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Bandwidth (first)	5 GHz
Bandwidth (second)	2.4 GHz
Mobile network connection	No
WLAN data transfer rates supported	600, 1300 Mbit/s
Antenna gain level (max)	3 dBi
Output current	2.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Routing protocols	IP
Security algorithms	WPA, WPA2, WPA2-PSK, WPS
Certification	CE, FCC, RoHS, BSMI, NCC, EAC, C-tick, IC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	76.6 mm
Width	226 mm
Height	179.5 mm
Weight	1210 g
