Tenda AC15 User Manual

63
Note
1. DO NOT remove the USB drive when it is working to avoid data loss or other damages.
2. DO NOT concurrently connect two or more external hard drives to the router’s USB3.0 port with
the help of a USB hub to avoid possible damages to the router.
To access the USB drive
Log in to the Router’s User Interface, and click USB Application > File Share.
Page Info
sda
When a USB storage drive is attached, the Router will detect it automatically
and this place will display the free space of it. Click Safely Eject button on the
right after use.
Guest Account &
Password
The File Share includes FTP server and Samba Server. Both of the servers use the
same account and password. The default account is admin which isn’t editable.
But you can specify a password to access the servers.
LAN devices visit
The addresses displayed here will be changed with the LAN address.
On LAN computer, visit the FTP server using ftp://xxx.xxx.xxx.xxx:xx; visit the
Samba server using \\xxx.xxx.xxx.xxx.
WAN devices visit
The address displayed here will be changed with the WAN address.
On WAN computer, visit the FTP server using the address displayed here.

Tenda AC15 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, System, USB, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
Bandwidth (first)	5 GHz
Bandwidth (second)	2.4 GHz
Mobile network connection	No
WLAN data transfer rates supported	600, 1300 Mbit/s
Antenna gain level (max)	3 dBi
Output current	2.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Routing protocols	IP
Security algorithms	WPA, WPA2, WPA2-PSK, WPS
Certification	CE, FCC, RoHS, BSMI, NCC, EAC, C-tick, IC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	76.6 mm
Width	226 mm
Height	179.5 mm
Weight	1210 g
