Tenda O3 User Manual

118
Parameters Description
Name
Description
IP Address of Peer AP
It specifies the LAN IP address of peer CPE. You can enter one manually.
IP Address
If the IP Address of Peer AP is set to Manual, you need to enter the LAN IP address of peer CPE in
the box manually.
HTTP Port
It specifies the port number of HTTP service. Default: 80. You are recommended to keep the
default value.
User Name
It specifies the user name of web UI of peer CPE.
Password
It specifies the password of web UI of peer CPE.
Test Group
It specifies the number of test connection launched by the client. Range: 1 to 20.
Direction
It specifies the test speed direction.
RX (Receive): only test the speed that the peer device transmits data to this device.
TX (Transit): only test the speed that this device transmits data to peer device.
Bidirectional: test the speed that this device transmits data to peer device and the peer device
transmits data to this device.
Time
It specifies the period of speed test.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
