Tenda O3 User Manual

84
Name
Description
Key Update Interval
It specifies interval at which a WPA key is updated. A shorter interval leads to higher security. The
value 0 indicates that no key update is performed.
Isolate Client
Enable: It indicates that the wireless clients connected to the CPE with the selected SSID cannot
communicate with each other. This improves wireless network security.
Disable: It indicates that the wireless clients connected to the CPE with the selected SSID can
communicate with each other. By default, it is disabled.
Max. Number of Clients
It specifies the maximum number of wireless clients that can be connected to the wireless
network with the SSID.
After this upper limit is reached, the CPE rejects new requests from clients for connecting to the
wireless network.
None
It indicates that any wireless client can connect to the wireless network. This option is not recommended
because it affects network security.
WEP

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
