Tenda W330R User Manual

Wireless-N Broadband Router
Contents
Chapter 1: Introduction.......................................................1
Package Contents...........................................................2
Chapter 2: Getting to Know the Wireless-N Broadband
Router...................................................................................3
The Rear Panel................................................................3
The Front Panel...............................................................4
Hardware Installation......................................................6
Chapter 3: Getting to Connect the Wireless-N Broadband
Router...................................................................................7
How to Set the Network Configurations for My
Computer.........................................................................7
How to Check the Network Connection........................9
Chapter 4 Basic Configurations.......................................10
How to Access the Web-based Configuration Utility.10
Setup Wizard .................................................................11
Chapter 5: Advanced Settings .........................................16
LAN Settings .................................................................16
WAN Settings—PPPoE.................................................17
WAN Settings—Static IP...............................................19
WAN Settings—L2TP....................................................20
2

Tenda W330R Specifications

General

Bandwidth	2.4 GHz
Input voltage	110 - 240 V
xDSL connection	No
Power requirements	AC 9 V, 1.2 A
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet, WLAN
Ethernet LAN	Yes
Receiver sensitivity	270M: -70dBm@10% PER; 130M: -70dBm@10% PER; 108M: -70dBm@10% PER; 54M: -73dBm@10% PER; 11M: -85dBm@8% PER; 6M: -88dBm@10% PER; 1M: -90dBm@8%
Antenna gain level (max)	2.5 dBi
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	6 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
